# Planning a Commercial Electrical Service Upgrade: A Step-by-Step Guide

by [Michael Zilliox](https://www.cdielectric.com/cdi-electric-blog/author/michael-zilliox) | Mar 10, 2026

- <https://www.facebook.com/sharer/sharer.php?u=https://www.cdielectric.com/cdi-electric-blog/why-a-licensed-commercial-electrician-should-lead-your-service-upgrade&title=Planning%20a%20Commercial%20Electrical%20Service%20Upgrade:%20A%20Step-by-Step%20Guide&picture=https://243338117.fs1.hubspotusercontent-na2.net/hubfs/243338117/Planning%20a%20Commercial%20Electrical%20Service%20Upgrade%20A%20Step-by-Step%20Guide%20Commercial%20Electrician%20in%20Cincinnati%20&%20NKY-%20CDI%20Electric.jpg&description=How%20to%20plan%20a%20commercial%20or%20industrial%20electrical%20service%20upgrade:%20load%20data,%20fault%20current,%20utility%20coordination,%20permits,%20shutdown%20planning,%20and%20closeout.>
- <https://twitter.com/share?source=https://www.cdielectric.com/cdi-electric-blog/why-a-licensed-commercial-electrician-should-lead-your-service-upgrade&text=Planning%20a%20Commercial%20Electrical%20Service%20Upgrade:%20A%20Step-by-Step%20Guide%20-%20https://www.cdielectric.com/cdi-electric-blog/why-a-licensed-commercial-electrician-should-lead-your-service-upgrade>
- <http://www.linkedin.com/shareArticle?mini=true&url=https://www.cdielectric.com/cdi-electric-blog/why-a-licensed-commercial-electrician-should-lead-your-service-upgrade&title=Planning%20a%20Commercial%20Electrical%20Service%20Upgrade:%20A%20Step-by-Step%20Guide&summary=How%20to%20plan%20a%20commercial%20or%20industrial%20electrical%20service%20upgrade:%20load%20data,%20fault%20current,%20utility%20coordination,%20permits,%20shutdown%20planning,%20and%20closeout.>
- <http://www.printfriendly.com/print?url=https://www.cdielectric.com/cdi-electric-blog/why-a-licensed-commercial-electrician-should-lead-your-service-upgrade>

If your building or plant is adding equipment, EV chargers, HVAC capacity, or a new production line, or if the main electrical equipment is simply near the end of its life, this guide walks through how a service upgrade is planned. It covers:

- Proving how much capacity you need
- What the utility needs from you
- What changes on the labels
- How to keep the shutdown from disrupting operations

---

## What a service upgrade includes

The service is where utility power enters your building: the service conductors, the meter, and the main service equipment. A commercial or industrial upgrade can also involve:

- Switchboards or switchgear, and the feeders leaving them
- Panelboards and distribution equipment downstream
- Transformers and three-phase distribution
- Grounding and bonding
- Metering and, in some cases, utility transformer changes

An upgrade is rarely just a bigger panel. It changes how much power the building can carry, how much fault current the equipment must withstand, and how the work has to be scheduled around operations.

## Signs you may need one

- You are adding significant load, such as machinery, refrigeration, EV charging, or HVAC, and nobody can say whether the existing service can carry it.
- The main or feeder breakers trip during peak operation.
- The service equipment has no spare capacity or space for new circuits.
- The equipment is old, damaged, or hard to find parts for.
- The utility plans to change the transformer serving your building.

None of these signs proves you need an upgrade. Each is a reason to measure before you buy equipment.

![commercial and industrial electrical services-power system upgrades-electrician in cincinnati and nky-CDI Electric](https://www.cdielectric.com/hs-fs/hubfs/commercial%20and%20industrial%20electrical%20services-power%20system%20upgrades-electrician%20in%20cincinnati%20and%20nky-CDI%20Electric.jpg?width=500&height=500&name=commercial%20and%20industrial%20electrical%20services-power%20system%20upgrades-electrician%20in%20cincinnati%20and%20nky-CDI%20Electric.jpg)

---

## Step 1: Gather what you already have

Before a contractor can size anything, collect:

- **12 months of utility bills that show peak demand in kW.** Many commercial bills show it.
- **A list of new equipment** with nameplate voltage, phase, and full-load amps.
- **Existing drawings:** a one-line diagram and panel schedules, even if they are out of date.
- **Your growth plans for the next several years,** so the upgrade isn't outgrown on day one.

## Step 2: Find out how much load you actually have

The NEC lets you determine an existing building's load from real demand data instead of a calculation based on every nameplate. Under section 220.87, a contractor can use one year of maximum demand data, usually from the utility. If a full year isn't available, the contractor can record demand for at least 30 days, in 15-minute intervals, while the building is occupied. The recording must also account for the larger of the heating or cooling load and any seasonal loads.

Multiply the highest demand by 125 percent and add it to the new load. The total must fit within the rating of the service or feeder.

**Why this matters to you:** measured demand often shows more spare capacity than a paper calculation, and sometimes it shows the new load fits without a full service upgrade. Utilities may need the owner's written permission before releasing demand data, so ask for it early.

## Step 3: Account for fault current and labels

A larger service, a shorter conductor run, or a new utility transformer can raise the available fault current at your equipment. That is the current that flows during a short circuit, and your equipment has to be rated to interrupt or withstand it.

Two NEC requirements follow from this:

- **Available fault current marking (NEC 110.24).** Service equipment in buildings other than dwellings must be field-marked with the available fault current and the date it was calculated. When a change affects the fault current, verify or recalculate the value and update the marking.
- **Arc flash labels (NEC 110.16(B)).** Under the 2023 NEC, service equipment and feeder-supplied equipment rated 1,000 amps or more, in buildings other than dwellings, must carry a permanent arc flash label that follows industry practice and shows the date it was applied.

Ask early in the project who will perform these calculations and labels, and include them in the bid. Leaving them out is a common source of late change orders.

## Step 4: Coordinate with the utility

Any change to the service involves your utility. Duke Energy, which serves much of Greater Cincinnati and Northern Kentucky, takes service requests from builders and contractors through its [Builder Portal](https://www.duke-energy.com/partner-with-us/builders-developers-and-contractors/discover-builder-portal). Requests are tracked there, including the date your site will be ready for the utility. Some buildings in the region are served by other utilities, so confirm your provider first.

Utility work often sets the schedule. Your contractor should start this step as soon as the design is firm enough to submit.

## Step 5: Permits and inspections

Service work needs an electrical permit, and in both Kentucky and Ohio the permit has to be issued to a licensed electrical contractor. The final inspection has to pass before the new service can be energized and used. For the details by jurisdiction, see [Electrical Code and Permits for Commercial Properties in Kentucky and Ohio](https://www.cdielectric.com/cdi-electric-blog/why-electrical-code-compliance-protects-your-property-investment).

## Step 6: Plan the shutdown

Most service upgrades need at least one planned outage. Good planning keeps it short and predictable.

- **Choose the window** that does the least harm, such as a weekend, an overnight, or a planned production shutdown.
- **Decide what must stay powered.** Temporary power or a rental generator may cover critical loads.
- **Notify tenants and staff** with dates, times, and what will be off.
- **Protect sensitive equipment.** Shut down servers, controls, and process equipment in the right order.
- **Agree on lockout/tagout responsibilities** between your team and the contractor.
- **Plan the restart.** Decide the order loads come back on, and who confirms each system is working.

## Step 7: Close out and document

When the work is done, you should receive:

- Updated panel schedules and a one-line diagram
- Available fault current markings and arc flash labels with dates
- Test results and inspection approvals
- As-built drawings showing what was installed

These records are the starting point for your maintenance program. See [How Often Should Electrical Equipment Be Tested?](https://www.cdielectric.com/cdi-electric-blog/how-often-should-electrical-equipment-be-tested)

![commercial and industrial electrician-industrial electrical service-CDI Electric](https://www.cdielectric.com/hs-fs/hubfs/commercial%20and%20industrial%20electrician-industrial%20electrical%20service-CDI%20Electric.jpg?width=500&height=281&name=commercial%20and%20industrial%20electrician-industrial%20electrical%20service-CDI%20Electric.jpg)



Service upgrade planning checklist

---

| ✓ | Item |
| --- | --- |
| ☐ | Collected 12 months of utility bills showing peak demand in kW |
| ☐ | Authorized the utility to release demand data, if needed |
| ☐ | Listed new equipment with nameplate voltage, phase, and amps |
| ☐ | Located existing one-line diagram and panel schedules |
| ☐ | Decided the planning horizon for future growth |
| ☐ | Asked whether a 30-day load study is needed |
| ☐ | Confirmed who calculates fault current and provides arc flash labels |
| ☐ | Confirmed the utility and started the service request |
| ☐ | Confirmed who pulls the permit and schedules inspections |
| ☐ | Picked a shutdown window and decided what needs temporary power |
| ☐ | Notified tenants and staff |
| ☐ | Agreed on lockout/tagout responsibilities |
| ☐ | Wrote the restart order and who verifies each system |
| ☐ | Listed the closeout documents you expect to receive |

---



## Questions to ask before you approve the upgrade

1. Is the sizing based on measured demand or on a calculation? Can I see it?
2. How much room does this design leave for future load?
3. Does the new equipment's rating cover the available fault current after the change?
4. Who provides the fault current marking and the arc flash labels?
5. What does the utility need from us, and when?
6. How long will the outage be, and what stays powered?
7. What documents will we receive at the end?

## What you can do, and what needs a licensed electrician

You can gather bills, equipment lists, and drawings, choose the shutdown window, and coordinate with tenants. Load studies, design, utility submissions for service work, permits, and all work on service equipment require a licensed electrical contractor. Service equipment carries the highest fault energy in the building. Only qualified persons should open it or work near it, following safe work practices.

## How CDI Electric can help

CDI Electric plans and installs commercial and industrial service upgrades across Northern Kentucky and Greater Cincinnati. We cover the load evaluation, utility coordination, permits, and planned shutdowns. If you are adding load or replacing aging service equipment, see our [commercial electrical services](https://www.cdielectric.com/services/commercial-electrician-cincinnati-nky) or [industrial electrical services](https://www.cdielectric.com/services/industrial-electrician-cincinnati-nky).

You can also call [859-291-9189.](tel:8592919189)

For a business owner, that translates to fewer callbacks, less troubleshooting, and more confidence that your electrical system will hold up under daily use. It also supports future upgrades more easily because the system is documented, labeled, and built for expansion.

---
